CP185 KD T4 Portable 185 cfm Air Compressor


In-Store Purchase or Rent


In-Store Purchase or Rent

Chicago Pneumatic’s CPS185 KD T4F portable diesel compressor is built to deliver reliable performance and flexibility for a wide range of general construction applications.  It’s quiet and easy to use, thanks to a proven 4-cylinder, naturally aspirated Kubota engine, a noise-reducing enclosure and straightforward controls.

User Friendly Controls – CP’s new intuitive controller make the transition to Final Tier 4 easy.  It takes the guesswork out of operation and provides a long list of diagnostics and protective shutdowns.

Low-Maintenance Design – Few moving parts minimize mechanical wear.  In addition, the durable galvanized sheet metal enclosure with powder-coat paint helps reduce noise and corrosion.

Convenient Transport – The tow-able design has an adjustable height hitch, jack stand and safety chains, as well as recessed towing lights and torsion bar suspension.


  • Galvanized enclosure to prevent rust
  • Central point drains for quick serviceability
  • Curbside control panel for ease of use
  • Protective shutdown system to prevent damage.

Rent or Own

Actual Free Air Deliverycfm
Normal Effective Working Pressurepsi100
Maximum Unloading Working Pressurepsi125
Working Pressure Rangepsi58-125
Discharge Outlet Quantity2 x 3/4″


Engine ModelKubota V2403
No of Cylinders4
US EPA EmissionsTier 4 Final
Cooling SystemWater (PAR Cool)
Engine Powerhp49
Displacementin3 (l)147 (2.4)
Rated Speed (high)rpm2700
Rated Speed (low)rpm1600
Fuel Consumption @ 100% loadgal/hr2.3
Fuel Tank Capacitygal20
Sound Pressure Level @ 23′ @75% loaddBa76

Dimensions & Weight

Overall Lengthin131
Overall Widthin60
Overall Heightin55.25
Weight Wetlb2400


  • Rotair D185T4F 185 cfm Portable 49.64 HP Diesel Powered Compressor
  • Engine: Kubota 49.64HP V2403-M-DI 4 cylinder Diesel
  • 185 cfm at 100 psi
  • 12-volt electrical system with alternator
  • 23.25-gallon fuel tank
  • Five-Year, Unlimited-Hour Warranty
  • Powerful and fuel-efficient
  • Weight:1860 lbs
