Spectra Precision Laser LL500-4

Availability:

In stock


$1,510.00

In stock

The Spectra LL500 Laser Level is self-leveling within ±11 arc minutes – less than one degree. The highly visible beam automatically locates the laser plane and the automatic leveler helps level the instrument on a tripod. The LL500 is accurate up to ±1/16 inch at 100 feet and has a working range of up to 1,600 feet.

With an easy one-button operation, the Spectra LL500 self-leveling laser is ideal for digging septic tanks, checking foundations or elevations, taking grade shots or setting forms. It also has an out-of-level alert that automatically shuts off the beam if it is bumped out of level.

This Spectra laser level features temperature compensation that enables the laser to adjust and work despite temperature changes. In addition, the housing is rugged enough for daily use on construction sites. The LL500 laser level works up to 100 hours using the rechargeable batteries and up to 175 hours with alkaline batteries.

SKU: LL500-4 Category: Tag:
  • Self-Leveling Range: ± 11 arc minutes
  • Compensation Type: Wire Hung, Air Damped
  • Accuracy: 1.5 mm at 30 m (1/16 in at 100 ft) ±10 arc seconds
  • Temperature Compensation: Yes
  • Laser Type: 670 nm visible, Class II
  • Machine Control Compatible: Yes
  • Battery Life 20°C (68°F): 4 D-Cell Alkaline – 175 hrs, NiMH – 100 hrs, NiCad – 75 hrs
  • Operating Diameter: 500 m (1,600 ft)
  • Operating Temperature: -20°C to 50°C (-4°F to 122°F)
  • Weight: 3.6 kg (8 lbs)
  • Tripod Mount: 5/8 in x 11
  • Warranty: 2 Years Use-and-Abuse

Includes

  • LL500 Laser Level
  • HL700 Receiver with Rod Clamp C70
  • (4) D-Cell Rechargeable NiMH Batteries Q103077
  • Charger 110-Volt AC Q102734
  • Small Carrying Case
  • Operating Manual

Features

  • Up to 1,600-foot range with laser receiver
  • Self-leveling within ±11 arc minutes
  • ±1/16 inch accuracy at 100 feet
  • Out-of-level alert
  • 360-degrees reference
  • One rotation speed
  • Great for control, excavations, slopes on grade, leveling forms and footers, screeding, and more
  • Height of instrument alert, with automatic shut off and LED flash alert
  • Temperature compensation
  • Dustproof and water resistant to IP66
  • 5/8-11 tripod thread

Specs

  • Self-Leveling Range: ± 11 arc minutes
  • Compensation Type: Wire Hung, Air Damped
  • Accuracy: 1.5 mm at 30 m (1/16 in at 100 ft) ±10 arc seconds
  • Temperature Compensation: Yes
  • Laser Type: 670 nm visible, Class II
  • Machine Control Compatible: Yes
  • Battery Life 20°C (68°F): 4 D-Cell Alkaline – 175 hrs, NiMH – 100 hrs, NiCad – 75 hrs
  • Operating Diameter: 500 m (1,600 ft)
  • Operating Temperature: -20°C to 50°C (-4°F to 122°F)
  • Weight: 3.6 kg (8 lbs)
  • Tripod Mount: 5/8 in x 11
  • Warranty: 2 Years Use-and-Abuse
